首頁> 產品展示> 控制器> 6管
6管采用磁場定向控制技術、功率驅動級采用SVPWM調制、提供給電機三相矢量控制型正弦波電流輸出；32位元的微處理器內核，系統表現出優異的運算能力和任務處理能力，可以同時處理轉矩環、勵磁環、速度環等高實時性要求的任務。
直接轉矩控制，起步平滑，加速性能好，在中、高速度段加速性能尤其突出，近似燃油摩托車操控性能。矢量控制型正弦波電流輸出轉矩更平滑，充分抑制電機轉矩波動而引起的低頻噪音。
| Specification: | |
| Size | 100mm×60mm×25mm |
| Rated Voltage | DC24V/DC36V |
| Rated Power | 250W |
| Low Voltage protection | DC21.5V(±0.5V)/DC31.5V(±0.5V) |
| Current Limit | 12A(±0.5A)/15A(±0.5A) |
| Standby Power Consumption | <2W |
| Housing Materials | Aluminum |
| Water Proof | IPX6 |
| Motor Matching | Sensored Motor /Sensorless Motor |
| Display Matching | LED Display/ LCD Display |
| Functions &Features: | |
| Super low noise | Reduce the motor torque ripple to minimum; achieve vehicle nois-e-free, vibration-free and comfortable riding feeling. |
| High efficiency | Field oriented control(FOC)sine-wave driving technology allows hi-gher system efficiency, lower heat loss and longer riding mileage. |
| Multiple Protections | Over-current protection,over-voltage/under-voltage protection, ov-er-heat protection, runaway protection, short-circuit protection, ph-ase wire disconnect protection, blockage protection. |
| Auto-sleep | When parking for more than 10 minutes without any operation, th-e system auto-matically power off to save battery power. |
| Flexible configuration | Parameter settings can be modified through USB interface with th-e computer, or through display. Parameter include current limit val-ue, low voltage protection value, sensor type, maximum speed, po-wer ratio etc. |
| EN15194 | All the controller specifications and functions are 100% guarantee-d to pass the EN15194 test. |
